Vibrating Inspection machine for automotive accessory

 Description

Machine used for inspecting the flatness of vehicle wheel casing after assemblied. The main inspection standard is to check and calculate the flatness after rotate the flange face for 360 degree, and save the data into barcode for tracing the product details.


 Specfication


Airpressure

0.3Mpa~0.6Mpa

Dimension

1120mm×630mm×1900mm

CT

15S/PCS

Weight

500kg

Power

AC220V 50-60HZ

Power

1KW

Control power

DC24




 Data comparation


Item

Manual mode

Machine mode

Cycle time

30s/pcs

15s/pcs

Operator

5

1

Description

1. The repeatbility position of relative datum level not accurately.the inspection data not enough.
2. The precision level only can meet milimeter
3. Hard to save and trace the data.

1.Operator only loading parts, machine working for all inspection process, which can fully and precisely inspect the parts.
2. Machine can reach the micron level, and ensure the repeatbility position,
3 Data can be easily save and trace,  and more reliable.






 Advantage

1.High working effciency, productitivty has improve 50%.

2.Machine-human type, manually loading parts, and fully automatic inspection process, save and trace data.

3. All parts data will combine with barcode for easy tracing data.
